Extended Spec
| General |
|
| Device Type |
Storage enclosure |
| Enclosure Type |
Rack-mountable - 5U |
| Chassis |
|
| Built-in Devices |
2 x 3-port environmental service module (ESM) |
| Supported Devices / Modules Qty |
84 |
| Supported Drives |
SAS-3 |
| Storage |
|
| Max Supported Capacity |
3360 TB |
| Processor |
|
| CPU |
No CPU |
| Hard Drive |
|
| Type |
No HDD |
| Expansion / Connectivity |
|
| Expansion Bays |
84 (total) / 84 (free) x hot-swap - 3.5" |
| Interfaces |
6 x SAS 12Gb/s - 36 pin 4x Mini SAS HD (SFF-8644) ¦ (management) |
| Miscellaneous |
|
| Compliant Standards |
CISPR 22 Class A, BSMI CNS 13438 Class A, EN55024, CCC, ICES-003 Class A, RoHS, EN 60950-1, FCC Part 15 A, GB 17625.1, GB 9254 Class A, VCCI Class B, EAC, NMB-3 Class A, GB 4943.1, CNS 14336, NOM-019, EN 55022 Class A, UL/CSA60950-1 |
| Power |
|
| Power Device |
2 x internal power supply - hot-plug |
| Max Supported Qty |
2 |
| Power Redundancy |
Yes |
| Power Redundancy Scheme |
1+1 |
| Voltage Required |
AC 120/230 V - 50/60 Hz |
| Power Provided |
2214 Watt |
| Dimensions & Weight |
|
| Width |
44.7 cm |
| Depth |
93.3 cm |
| Height |
22.1 cm |
| Weight |
131 kg |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 3 years |
| Environmental Parameters |
|
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
20 - 80% (non-condensing) |
