Extended Spec
| General |
|
| Device Type |
Storage enclosure |
| Enclosure Type |
Rack-mountable - 2U |
| Chassis |
|
| Supported Devices / Modules Qty |
12 |
| Supported Drives |
SAS-3 |
| Processor |
|
| CPU |
No CPU |
| Hard Drive |
|
| Type |
No HDD |
| Expansion / Connectivity |
|
| Expansion Bays |
12 (total) / 12 (free) x hot-swap - 3.5" LFF |
| Interfaces |
8 x SAS 12Gb/s - 36 pin 4x Mini SAS HD (SFF-8644) |
| Miscellaneous |
|
| Cables Included |
4 x mini SAS HD cable - 1 m ¦ 2 x power cable (C13-C14) - 1.5 m |
| Compliant Standards |
BSMI CNS 13438 Class A, NOM, EN55024, ICES-003 Class A, UL 60950-1, FCC Part 15 A, GB 17625.1, GB 9254 Class A, CECP, CEL, Directive 2011/65/EU, VCCI Class A, EAC, GB 4943.1, KN32, KN35, CNS 14336-1, EN 55032 Class A, IEC/EN 60950-1, CAN/CSA-C22.2 No. 60950-1, AS/NZS CISPR22 Class A |
| Included Accessories |
Rack mounting kit |
| Power |
|
| Power Device |
2 x internal power supply - hot-plug |
| Max Supported Qty |
2 |
| Power Redundancy |
Yes |
| Power Redundancy Scheme |
1+1 |
| Voltage Required |
AC 120/230 V - 50/60 Hz |
| Power Provided |
913 Watt |
| Dimensions & Weight |
|
| Width |
44.7 cm |
| Depth |
48.3 cm |
| Height |
8.5 cm |
| Weight |
27.6 kg |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 3 years - on-site |
| Environmental Parameters |
|
| Min Operating Temperature |
10 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
8 - 90% (non-condensing) |
