Extended Spec
| General |
|
| Device Type |
Storage enclosure |
| Enclosure Type |
Rack-mountable - 5U |
| Chassis |
|
| Built-in Devices |
2 x I/O module |
| Installed Devices / Modules Qty |
140 |
| Supported Drives |
SAS-3 |
| Storage |
|
| HDD Array External Interface |
SAS 12Gb/s |
| Expansion / Connectivity |
|
| Expansion Bays |
140 (total) / 140 (free) x hot-swap - 3.5" LFF |
| Interfaces |
1 x SAS 12Gb/s |
| Hard Drive |
|
| Type |
No HDD |
| System Requirements |
|
| OS Required |
SuSE Linux Enterprise Server, Microsoft Windows Server 2003, Red Hat Enterprise Linux, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, VMware ESX |
| Miscellaneous |
|
| Features |
Redundant fans, 92% efficiency power supply |
| Compliant Standards |
80 PLUS Gold |
| Power |
|
| Power Device |
4 x internal power supply - hot-plug |
| Max Supported Qty |
4 |
| Power Redundancy |
Yes |
| Power Redundancy Scheme |
N+1, N+2 |
| Voltage Required |
AC 120/230 V - 50/60 Hz |
| 80 PLUS Certification |
80 PLUS Gold |
| Dimensions & Weight |
|
| Width |
44.7 cm |
| Depth |
89.12 cm |
| Height |
22.1 cm |
| Weight |
72.58 kg |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - parts - 3 years |
| Environmental Parameters |
|
| Min Operating Temperature |
10 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
10 - 90% (non-condensing) |
