Extended Spec
| General |
|
| Device Type |
Switch - 8 ports - unmanaged |
| Enclosure Type |
Rack-mountable |
| Subtype |
10 Gigabit Ethernet |
| Ports |
8 x 100/1000/2.5G/5G/10GBase-T |
| Performance |
Switching fabric bandwidth: 160 Gbps ¦ Forwarding rate: 119.04 Mbps ¦ Latency (100 Mbps): 12.7 µs ¦ Latency (1 Gbps): 3.7 µs ¦ Latency (2.5 Gbps): 6.2 µs ¦ Latency (5 Gbps): 4.1 µs ¦ Latency (10 Gbps): 3.1 µs |
| Capacity |
Packet buffer size: 1.5 MB |
| MAC Address Table Size |
16K entries |
| Jumbo Frame Support |
12KB |
| Features |
Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, full duplex mode, fanless, built-in DIP switch, Loop Guard, EEE, LDF support, non-blocking architecture |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz |
| Status Indicators |
Power, system, link/activity, loop, speed/loop |
| Expansion / Connectivity |
|
| Interfaces |
8 x 100/1000/2.5G/5G/10GBase-T RJ-45 |
| Power |
|
| Power Device |
Internal power supply |
| Voltage Required |
AC 100-240 V (47 - 63 Hz) |
| Electric Current Required |
0.6 A |
| Miscellaneous |
|
| Included Accessories |
Power cord retention clip |
| Compliant Standards |
Plug and Play, EN 61000-3-2, NOM, EN 61000-3-3, RoHS, cULus, FCC Part 15 B Class A, EMI, VCCI Class A, EAC, EN 61000-4-2:2009, EN 61000-4-11:2004, RCM, EN 61000-3-3:2013, EN 61000-4-3:2006+A1:2008+A2:2010, EN 61000-4-8:2010, EN 61000-4-6:2014, EN 61000-3-2:2014, EN 61000-4-5:2014, EN 55032:2012+AC:2013 Class A, CISPR 32:2012 Class A, ICES-003:2016 issue 6 Class A, UL 62368-1, AS/NZS CISPR32:2013 Class A, EN 55035:2017, EN 61000-4-4:2012, IEC/EN 62368-1, UKCA |
| Localisation |
United Kingdom |
| Dimensions & Weight |
|
| Width |
21 cm |
| Depth |
27.5 cm |
| Height |
4.25 cm |
| Weight |
2.1 kg |
| Dimensions & Weight (Shipping) |
|
| Shipping Width |
26 cm |
| Shipping Depth |
43.5 cm |
| Shipping Height |
10 cm |
| Shipping Weight |
2.78 kg |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 5 years |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
50 °C |
| Humidity Range Operating |
5 - 90% (non-condensing) |
| Min Storage Temperature |
-25 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
5 - 95% (non-condensing) |
