| General |
|
| Device Type |
Switch - 16 ports - L3 - Managed - stackable |
| Enclosure Type |
Rack-mountable 1U |
| Subtype |
5 Gigabit Ethernet |
| Ports |
16 x 100/1000/2.5G/5G (PoE++) + 2 x 1 Gigabit / 10 Gigabit SFP+ (uplink) |
| Power Over Ethernet (PoE) |
PoE++ |
| PoE Budget |
720 W |
| Performance |
Switching fabric speed: 200 Gbps ¦ Forwarding rate: 148.8 Mpps ¦ Stacking bandwidth: 40 Gbps ¦ Latency (100 Mbps): 8.35 µs ¦ Latency (1 Gbps): 7.96 µs ¦ Latency (2.5 Gbps): 7.72 µs ¦ Latency (5 Gbps): 5.23 µs ¦ Latency (10 Gbps): 2.56 µs |
| Capacity |
Virtual interfaces (VLANs): 4094 ¦ Packet buffer size: 3 MB ¦ OpenFlow flows: up to 1250 ¦ Priority queues: 8 |
| MAC Address Table Size |
16K entries |
| Jumbo Frame Support |
10KB |
| Max Units In A Stack |
8 |
| Routing Protocol |
OSPF, RIP, BGP-4, RIP-2, BGP, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, static IP routing, PIM-DM, IGMPv3, OSPF for IPv6, OSPFv3, PIM-SSM, MSDP, ECMP, policy-based routing (PBR), RIPng, MLDv2, MLD, VRRPv3, CIDR, MSTP, RSTP |
| Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI, SLP, SCP, SNMP 6, SSH 6, SFTP, SMTP, NTP, ICMP, DHCP, IPv6, RSTP, TACACS+, RADIUS |
| Encryption Algorithm |
DES, RSA, MD5, SHA-1, DSA, ECDSA, AES-ECB, 128-bit AES, 192-bit AES, 256-bit AES, AES-CBC, SHA-2, AES-CFB, AES-OFB, RNG, CCM, CMAC, GCM, XTS, DRBG, SHA-256, SHA-384, SHA-512, HMAC, SHA-224, 3DES |
| Authentication Method |
Secure Shell (SSH), RADIUS, X.509 certificates, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
| Features |
Auto-negotiation, BOOTP support, IGMP snooping, Syslog support, DoS attack prevention, DiffServ support, MAC address filtering, sFlow, DHCP snooping, ACL support, QoS, DHCP server, DAI, PVST+, STP Root Guard, UDLD, DHCP relay, RSPAN, NTP server, DNS relay, DHCP client, NAC, auto provisioning, MSDP, 802.1x authentication, OpenFlow support, MLD proxy, IP source guard, EPSRing, VCStack, BPDU, ICMP, black hole routing, CPP, SLP, AMF, BIST, Cable fault locator (TDR), SDN, DDM, MAC address authentication, Active Fiber Monitoring, AAA, Loop Guard, VLAN mirroring, DNS client, NTP client, Voice VLAN, CFM, LLDP-MED, storm protection, UDP, proxy ARP, EEE, VACM, router advertisement guard, PPP, BPDU protection, BPDU forward, CCP, automatic backups, AWC, eco-friendly button |
| Compliant Standards |
IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, ITU-T G.8032, IEEE 802.3bz, IEEE 802.3bt |
| RAM |
1 GB DDR3 SDRAM |
| Flash Memory |
256 MB |
| Status Indicators |
PoE, link/activity, switch ID |
| Expansion / Connectivity |
|
| Interfaces |
16 x 100/1000/2.5G/5G RJ-45 PoE++ - 90 W ¦ 2 x 1/10GBase-X SFP+ uplink ¦ 1 x console RJ-45 ¦ 1 x USB 2.0 Type A |
| Power |
|
| Power Device |
Internal power supply |
| Installed Qty |
1 |
| Voltage Required |
AC 100-240 V (50/60 Hz) |
| Electric Current Required |
10 A |
| Miscellaneous |
|
| Compliant Standards |
FCC Class A certified, UL, cUL, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, FIPS 140-2, UL 60950-1, EN 60950-1, EN 60825-1, CAN/CSA C22.2 No. 60950-1-03, VCCI Class A, China RoHS, EN 55032 Class A, EU RoHS |
| Localisation |
United Kingdom |
| Software / System Requirements |
|
| Software Included |
Alliedware Plus |
| Dimensions & Weight |
|
| Width |
44.1 cm |
| Depth |
25.6 cm |
| Height |
4.4 cm |
| Weight |
4.3 kg |
| Dimensions & Weight (Shipping) |
|
| Shipping Width |
52.6 cm |
| Shipping Depth |
41.2 cm |
| Shipping Height |
12.9 cm |
| Shipping Weight |
5.98 kg |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 5 years |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
50 °C |
| Humidity Range Operating |
5 - 90% (non-condensing) |
| Min Storage Temperature |
-25 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
5 - 95% (non-condensing) |
