| General |
|
| Product Type |
Smartphone |
| Manufacturer Model Number |
T509K |
| Form Factor |
Touch |
| Protection |
Anti-fingerprint coating |
| Integrated Components |
LED flashlight |
| Width |
76.67 mm |
| Depth |
8.32 mm |
| Height |
168.29 mm |
| Weight |
190 g |
| Body Colour |
Space grey |
| Cellular |
|
| Technology |
WCDMA (UMTS) / GSM |
| Mobile Broadband Generation |
4G |
| Service Provider |
Not specified |
| Operating System |
Android 14 |
| Navigation |
BDS, GPS, A-GPS, Galileo, GLONASS |
| SIM Card Type |
Nano SIM |
| SIM Card Qty |
Dual-SIM |
| Input Device |
Multi-touch |
| Communications |
|
| Data Transmission |
LTE, VoLTE, VoWiFi, HSPA+, GPRS, EDGE |
| 2G Band |
850 GSM, 900 GSM, 1800 GSM, 1900 GSM |
| 3G UMTS Band |
Band 1, Band 2, Band 5, Band 8 |
| 3G UMTS Frequency |
2100, 1900, 850, 900 |
| 4G LTE Band |
Band 1, Band 3, Band 5, Band 7, Band 8, Band 20, Band 26, Band 28, Band 38, Band 40, Band 41 |
| 4G LTE Frequency |
FDD 2100, FDD 1800+, FDD 850, FDD 2600, FDD 900, FDD 800 DD, FDD 850+, FDD 700 APT, TDD 2600, TDD 2300, TDD 2500 |
| Wireless Interface |
IEEE 802.11a/b/g/n/ac, Bluetooth 5.1, NFC |
| Phone Features |
|
| Sensors |
G-sensor |
| Security Devices |
Face recognition, fingerprint reader (side) |
| Security Technology |
Face Unlock |
| Additional Features |
Software updates FOTA (Firmware Over The Air), dual stereo speakers, Virtual Proximity Sensing |
| Media Player |
|
| Supported Digital Audio Standards |
AAC, HE-AAC v1, HE-AAC v2, AMR, AWB, MIDI, MP3, OGG, Vorbis, WAV (Alaw / Ulaw), WAV (Raw), FLAC, OPUS |
| Supported Digital Video Standards |
MPEG-2, H.263, MPEG-4, H.264, H.265, VP8, VP9 |
| Video Enhancements |
NXTURBO |
| Sound Enhancements |
Sound booster |
| Processor |
|
| Type |
MediaTek Helio G36 |
| Processor Number |
MT6765X |
| Clock Speed |
2.2 GHz |
| Processor Core Qty |
8-core |
| Graphics System |
|
| Graphics Accelerator |
IMG GE8320 |
| Memory |
|
| RAM |
4 GB + up to 4 GB virtual extension |
| Internal Memory Capacity |
128 GB |
| User Memory |
108 GB |
| Supported Flash Memory Cards |
microSD, microSDHC, microSDXC - up to 512 GB |
| Front Camera |
|
| Sensor Resolution |
5 Megapixel |
| Sensor Size |
1/5" |
| Lens Aperture |
F/2.2 |
| Lens Element Qty |
3-element |
| Focus Adjustment |
Focus free |
| Field of View (FoV) |
76.8 degree(s) |
| Pixel Size |
1.12 µm |
| Camera Modes |
Gesture Capture |
| Main Camera |
|
| Sensor Resolution |
50 Megapixel |
| Sensor Size |
1/2.55" |
| Lens Aperture |
F/1.8 |
| Lens Construction |
5-element |
| Field of View (FoV) |
79.4 degree(s) |
| Pixel Size |
0.7 µm |
| Focus Adjustment |
Automatic |
| Special Effects |
HDR |
| Camera Modes |
Panorama, Bokeh Mode, Face Beauty |
| Face Detection |
Face tracking |
| Light Source |
LED flash |
| Video Resolutions |
1920 x 1080 (1080p) at 30 fps |
| Features |
Phase Detect Auto-Focus (PDAF), AI scene detection |
| Second Camera |
|
| Sensor Resolution |
2 Megapixel |
| Sensor Size |
1/5" |
| Lens Aperture |
F/2.4 |
| Lens Element Qty |
3-element |
| Field of View (FoV) |
88.8 degree(s) |
| Pixel Size |
1.75 µm |
| Functions |
Macro camera |
| Display |
|
| Diagonal Size |
6.75" |
| Display Resolution |
1612 x 720 pixels |
| Display Format |
HD+ |
| Pixel Density |
260 ppi |
| Aspect Ratio |
20:9 |
| Max Brightness |
400 cd/m² |
| Enhancement Technology |
Eye Care, blue light filter |
| Refresh Rate |
90 Hz |
| Contrast Ratio |
1500:1 |
| Features |
TCL NXTVISION, 2.5D Glass, capacitive touch screen, 70% NTSC |
| Connections |
|
| Connector Type |
Headset jack - mini-phone 3.5mm ¦ USB Type-C |
| Battery |
|
| Capacity |
5010 mAh |
| Recharge Time |
3 hour(s) |
| Miscellaneous |
|
| Included Accessories |
Power adapter, USB-C cable, LCD sticker, SIM card removal tool |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 2 years |
