Extended Spec
| General |
|
| Device Type |
Storage enclosure |
| Enclosure Type |
Rack-mountable - 4U |
| Chassis |
|
| Built-in Devices |
2 x I/O module |
| Installed Devices / Modules Qty |
106 |
| Supported Devices / Modules Qty |
106 |
| Supported Drives |
SAS-3 |
| Hard Drive |
|
| Type |
HDD - hot-swap |
| Capacity |
106 x 18 TB |
| Interface Type |
SAS 12Gb/s |
| Spindle Speed |
7200 rpm |
| Manufacturer |
Seagate |
| Expansion / Connectivity |
|
| Expansion Bays |
106 (total) / 0 (free) x hot-swap - 3.5" |
| Interfaces |
8 x SAS 12Gb/s - 36 pin 4x Mini SAS HD (SFF-8644) ¦ 4 x management - RJ-45 |
| Miscellaneous |
|
| Features |
Hot-swappable controllers, hot-swappable fans, hot-swappable IOM, out of band management, SCSI Enclosure Services (SES) |
| Compliant Standards |
ASHRAE Class A2, UL 60950-1, EN 60950-1, IEC 60950-1, CCC, BIS, Directive 2009/125/EC, AS/NZS CISPR 32 Class A, CNS 13438 Class A, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN55024, FCC CFR47 Part 15 B Class A, ICES-3(A)/NMB-3(A), KN24, KN35, VCCI Class A, FCC, RoHS 2011/65/EU, WEEE, KC, RCM, CAN/CSA-C22.2 No. 60950-1-07 |
| Power |
|
| Power Device |
Internal power supply - hot-plug |
| Power Redundancy |
Yes |
| Voltage Required |
AC 200-240 V 50/60 Hz |
| Power Provided |
2000 Watt |
| Dimensions & Weight |
|
| Width |
44.1 cm |
| Depth |
113.9 cm |
| Height |
17.64 cm |
| Weight |
141 kg |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 5 years |
| Environmental Parameters |
|
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
8 - 80% (non-condensing) |
