Extended Spec
| General |
|
| Device Type |
NAS server |
| Host Connectivity |
Gigabit Ethernet |
| Enclosure Type |
Rack-mountable - 1U |
| Total Storage Capacity |
4 TB |
| Max Supported Capacity |
40 TB |
| Installed Devices / Modules Qty |
4 (installed) / 4 (max) |
| Width |
43.46 cm |
| Depth |
60.76 cm |
| Height |
4.29 cm |
| Weight |
15 kg |
| UNSPSC Information |
43201835 - Network attached storage NAS device |
| Processor / Memory |
|
| Processors Installed |
1 x Intel Xeon E5-2603V3 1.6 GHz |
| Number of Cores |
6-core |
| Max Supported Qty |
2 |
| RAM |
8 GB DDR4 |
| Features |
Registered, single rank |
| Storage Controller |
|
| Type |
RAID |
| Interface Type |
SATA 6Gb/s / SAS 12Gb/s |
| RAID Level |
RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM |
| Hard Drive |
|
| Type |
HDD - hot-swap - 3.5" LFF |
| Capacity |
4 x 1 TB |
| Interface Type |
SATA 6Gb/s |
| Data Transfer Rate |
600 Mbps |
| Spindle Speed |
7200 rpm |
| Networking |
|
| Data Link Protocol |
10Mb LAN, 100Mb LAN, GigE |
| Network / Transport Protocol |
iSCSI |
| Network Services Compatibility |
DNS, DHCP, Microsoft CIFS, Network File System (NFS), FTP, FTPS, Server Message Block (SMB), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV) |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Expansion / Connectivity |
|
| Expansion Bays |
4 (total) / 0 (free) x hot-swap - 3.5" LFF |
| Miscellaneous |
|
| Features |
Built-in microSD slot |
| Included Accessories |
Rack mounting kit, cable management arm |
| Power |
|
| Power Device |
Internal power supply |
| Installed Qty |
1 |
| Max Supported Qty |
2 |
| Power Redundancy |
Optional |
| Power Redundancy Scheme |
1+1 (with optional power supply) |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Provided |
900 Watt |
| Software / System Requirements |
|
| Storage Operating System |
Microsoft Windows Storage Server 2012 R2 Standard |
| Software Included |
HPE iLO Advanced 1yr 24x7 Technical Support and Updates Single Server License |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - parts - 3 years - response time: next business day ¦ Limited warranty - parts and labour - 1 year - on-site - response time: next business day |
| Environmental Parameters |
|
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
8 - 90% (non-condensing) |
| Sound Emission |
34.2 dBA |
