| General |
|
| Device Type |
Switch - L3 - Managed |
| Enclosure Type |
Rack-mountable 6U |
| Subtype |
100 Gigabit Ethernet |
| Performance |
Switching capacity: 28.8 Tbps ¦ Throughput: 14.4 Bpps |
| Routing Protocol |
OSPF, EGP, RIP, BGP-4, IS-IS, RIP-1, RIP-2, BGP, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, PIM-DM, IGMPv3, GRE, OSPFv3, PIM-SSM, Bidirectional PIM, MSDP, static IPv4 routing, static IPv6 routing, ECMP, policy-based routing (PBR), RIPng, MLDv2, MLD, BGP-4+, MPLS, Bidirectional Forwarding Detection (BFD), CIDR, BGP for IPv6, BGP+ |
| Remote Management Protocol |
SNMP 1, SNMP 2, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, RMON, Telnet, SNMP 3, HTTP, TFTP, SSH, SSH-2 |
| Encryption Algorithm |
MD5, AES, IKE, TLS |
| Authentication Method |
Secure Shell (SSH), RADIUS, PAP, CHAP, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
| Features |
Flow control, NAT support, VPN support, ARP support, VLAN support, IGMP snooping, IPv6 support, Link Fault Signaling (LFS), Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, tunnelling, Data Center Bridging Exchange (DCBX) support, IPSec Virtual Private Network (VPN), DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, Per-VLAN Spanning Tree Plus (PVST+), Device Link Detection Protocol (DLDP) support, Bidirectional Forwarding Detection (BFD), Unicast Reverse Path Forwarding (URPF), IPv4 support, LACP support, LLDP support, DHCP relay, Link Aggregation Control Protocol (LACP), Port Security, Data Center Bridging (DCB), fan tray, DHCP client, Management Information Base (MIB), NTP time synchronisation, FCoE forwarding, Class of Service (CoS), UDP/IP offloading, Edge Virtual Bridging (EVB), Intelligent Resilient Framework Technology (IRF), Network Quality Analyzer (NQA), Multicast Source Discovery Protocol (MSDP), Multicast Border Gateway Protocol (MBGP), SNMP support, IP source guard |
| Compliant Standards |
IEEE 802.3, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.3ba, IEEE 802.1Qbb, IEEE 802.1Qaz |
| RAM |
8 GB DDR3 SDRAM |
| Flash Memory |
1 GB |
| UNSPSC Information |
43222612 - Network switches |
| Expansion / Connectivity |
|
| Expansion Slots |
4 (total) / 4 (free) x Expansion Slot ¦ 2 (total) / 2 (free) x MPU ¦ 6 (total) / 6 (free) x Switching Fabric Unit |
| Installed Modules Qty (Max) |
0 (installed) / 12 (max) |
| Power |
|
| Power Device |
Internal power supply |
| Installed Qty |
0 (installed) / 4 (max) |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Miscellaneous |
|
| Included Accessories |
Rack mount kit |
| Compliant Standards |
ETSI, CISPR 22 Class A, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, EN 6100-3-2, AS/NZS, VCCI Class A, EN 50581, ETS 300 386, FDA 21CFR1040.10, EN 55022 Class A, FCC CFR47 Part 15 A, CAN/CSA-C22.2 No. 60950-1, EN 300386 |
| Software / System Requirements |
|
| Software Included |
Command Line Interface (CLI), HP Intelligent Management Center |
| Dimensions & Weight |
|
| Width |
43.99 cm |
| Depth |
85.7 cm |
| Height |
26.39 cm |
| Weight |
36 kg |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - advance parts replacement - 1 year ¦ Limited warranty - phone consulting - 1 year ¦ Limited warranty - delivery - 10 days |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
| Min Storage Temperature |
-40 °C |
| Max Storage Temperature |
70 °C |
