| General |
|
| Device Type |
Switch - 24 ports - L3 - Managed |
| Enclosure Type |
Front to back airflow rack-mountable 1U |
| Subtype |
10 Gigabit Ethernet |
| Ports |
24 x 1 Gigabit / 10 Gigabit SFP / SFP+ + 2 x 40/100 Gigabit QSFP+ / QSFP28 |
| Performance |
Switching capacity: 880 Gbps |
| Capacity |
VLANs supported: 4094 ¦ IGMP groups: 7000 ¦ MLD groups: 7000 ¦ IPv4 routes (Multicast): 7000 ¦ IPv6 routes (Multicast): 7000 ¦ IPv4 ACL entries (egress): 8192 ¦ IPv6 ACL entries (egress): 2048 ¦ MAC addresses: 212992 ¦ Host table entries (IPv4): 145780 ¦ Host table entries (IPv6): 145780 ¦ IPv4 routes (Unicast): 606977 ¦ IPv6 routes (Unicast): 630784 ¦ IPv4 ACL entries (ingress): 65536 ¦ IPv6 ACL entries (ingress): 16384 ¦ MAC ACL entries (egress): 8192 ¦ MAC ACL entries (ingress): 65536 |
| Jumbo Frame Support |
9KB |
| Routing Protocol |
OSPF, BGP-4, BGP, IGMP, VRRP, PIM-SM, static IPv4 routing, static IPv6 routing, MLD, Bidirectional Forwarding Detection (BFD) |
| Remote Management Protocol |
SNMP, RMON, TFTP, CLI, SFTP, NTP, DHCP |
| Encryption Algorithm |
EAP-TLS |
| Authentication Method |
RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Features |
ARP support, sFlow, RSTP support, MSTP support, QoS, DCB, VRF, packet storm protection, Loopback, ERPS, ECN, RoCE v2, VSX, RPVST+, UDLD, VXLAN Distributed Anycast Gateway, VXLAN ARP/ND Suppression, REST API interface, job scheduler framework, dual flash Images, IP Directed Broadcast |
| Compliant Standards |
IEEE 802.1D, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1ab (LLDP) |
| Processor |
1: 1.8 GHz |
| RAM |
16 GB |
| Flash Memory |
32 GB |
| Expansion / Connectivity |
|
| Interfaces |
24 x 1/10Gbit LAN SFP+ ¦ 2 x 40/100Gbit LAN QSFP28/QSFP+ ¦ 1 x serial RJ-45 ¦ 1 x console Type C ¦ 1 x management Type A |
| Power |
|
| Power Device |
Internal power supply - hot-plug |
| Installed Qty |
2 |
| Max Supported Qty |
2 |
| Power Redundancy |
Yes |
| Power Provided |
550 Watt |
| Voltage Required |
AC 100-127/200-240 V (50/60 Hz) |
| Power Consumption Stand by |
120 Watt |
| Miscellaneous |
|
| Included Accessories |
3 fan trays, rack kit (2 post) |
| Rack Mounting Kit |
Included |
| Compliant Standards |
FCC Class A certified, CISPR 24, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1 Second Edition, VCCI Class A, EN 50581:2012, CNS 13438, CSA 22.2 No. 60950-1, EN 61000-3-3:2013, EN 55024:2010, CNS 13438 Class A, EN 55032:2015, CISPR 32 Class A, EN 61000-3-2:2014 Class A, cUL No.60950-1 Second Edition, CISPR 35, EN 55035:2017, IEC 62368-1: 2014, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, EN 62368-1:2014 Second Edition, IEC60950-1:2005, Second edition + Am1:2009 + A2:2013 |
| Dimensions & Weight |
|
| Width |
44.25 cm |
| Depth |
40.64 cm |
| Height |
4.4 cm |
| Weight |
8.07 kg |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - lifetime |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
15 - 95% (non-condensing) |
| Min Storage Temperature |
-40 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
15 - 95% (non-condensing) |
