Extended Spec
| General |
|
| Product Type |
Antenna |
| Product Material |
Polycarbonate |
| Depth |
18 cm |
| Height |
6.05 cm |
| Weight |
670 g |
| Cable Length |
61 cm |
| Enclosure Colour |
Black |
| Aerial |
|
| Form Factor |
Dome |
| Intended for |
Cellular |
| Aerial Placing / Mounting |
Outdoor, roof-mountable |
| Compatibility |
4G |
| Frequency Range |
698 - 960 MHz, 1710 - 2700 MHz, 1448 - 1511 MHz |
| Gain |
2.6 dBi (for 698 - 960 MHz), 4.6 dBi (for 1710 - 2700 MHz), 3.8 dBi (for 1448 - 1511 MHz) |
| Directivity |
Omni-directional |
| Voltage Standing Wave Ratio (VSWR) |
2.1:1 (for 698 - 960 MHz), 2.4:1 (for 1448), 2.2:1 (for 1448 - 1511 MHz), 2.0:1 (for 1710 - 2700 MHz) |
| Impedance |
50 Ohm |
| Cabling & Wiring |
|
| Compliant Standards |
RG-58 |
| Connector Provided |
2 x TNC male |
| Miscellaneous |
|
| Features |
UV protection, MIMO technology |
| Environmental Parameters |
|
| Min Operating Temperature |
-40 °C |
| Max Operating Temperature |
70 °C |
| Humidity Range Operating |
5 - 95% |
