Extended Spec
| General |
|
| Device Type |
Switch - 24 ports - Managed |
| Enclosure Type |
Desktop, rack-mountable 1U |
| Subtype |
Fast Ethernet |
| Ports |
24 x 10/100 + 2 x combo Gigabit SFP |
| Performance |
Forwarding performance (64-byte packet size): 6.55 Mpps ¦ Switching capacity: 8.8 Gbps |
| MAC Address Table Size |
8192 entries |
| Jumbo Frame Support |
9216 bytes |
| Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, CLI |
| Authentication Method |
RADIUS, TACACS+ |
| Features |
Flow control, Layer 2 switching, BOOTP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, MAC address filtering, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping, reset button, fanless, LLDP support, DHCP relay, DHCP client, Energy Efficient Ethernet, Generic Attribute Registration Protocol (GARP), Generic VLAN Registration Protocol (GVRP), Type of Service (ToS), 4.1MB packet buffer |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3az |
| RAM |
128 MB |
| Flash Memory |
32 MB |
| Status Indicators |
Port transmission speed, system, link/activity |
| UNSPSC Information |
43222612 - Network switches |
| Expansion / Connectivity |
|
| Interfaces |
24 x 100Base-TX RJ-45 ¦ 2 x 1000Base-T RJ-45 ¦ 2 x SFP |
| Power |
|
| Power Device |
Internal power supply |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Miscellaneous |
|
| Cables Included |
1 x console cable |
| Rack Mounting Kit |
Included |
| MTBF |
603,729 hours |
| Compliant Standards |
C-Tick, UL 60950, FCC CFR47 Part 15, CSA 22.2 |
| Localisation |
Europe |
| Dimensions & Weight |
|
| Width |
44 cm |
| Depth |
20.1 cm |
| Height |
4.4 cm |
| Weight |
2.6 kg |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - replacement - lifetime ¦ Technical support - web support - 1 year ¦ Technical support - phone consulting - 1 year ¦ Limited warranty - power supply and fans - 1 year ¦ Limited warranty - software - 90 days |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
50 °C |
| Humidity Range Operating |
10 - 90% (non-condensing) |
| Min Storage Temperature |
-20 °C |
| Max Storage Temperature |
70 °C |
