Extended Spec
General |
|
Device Type |
Network adapter |
Form Factor |
Plug-in card |
Interface (Bus) Type |
PCI Express 3.0 |
Networking |
|
Ports |
10 Gigabit SFP+ x 4 |
Connectivity Technology |
Wired |
Data Link Protocol |
10 Gigabit Ethernet |
Capacity |
MAC addresses per port: 128 ¦ Jumbo frame size: 9216 |
Features |
Traffic shaping, RDMA support, Large Send Offload (LSO), Receive Side Scaling (RSS), Single Root I/O Virtualization (SR-IOV), Extended Message-Signaled Interrupts (MSI-X), TCP/IP checksum offload, UDP/IP checksum offload, RDMA over Converged Ethernet (RoCE), Unified Fabric Port (UFP), RDMA over Converged Ethernet (RoCE) v2, Virtual Fabric mode, Switch Independent mode, Virtual Ethernet Bridge (VEB), Opens Fabrics Enterprise Distribution (OFED) |
Compliant Standards |
IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3p, IEEE 802.1ab (LLDP), IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qbg |
Expansion / Connectivity |
|
Interfaces |
4 - SFP+ |
Miscellaneous |
|
Included Accessories |
Low-profile bracket, full-height bracket |
Power |
|
Power Consumption Operational |
14.4 Watt |
Dimensions & Weight |
|
Depth |
16.7 cm |
Height |
11.1 cm |
Manufacturer Warranty |
|
Service & Support |
Limited warranty - 1 year |
Environmental Parameters |
|
Min Operating Temperature |
0 °C |
Max Operating Temperature |
55 °C |
Humidity Range Operating |
5 - 95% (non-condensing) |
