Extended Spec
| General |
|
| Device Type |
Network adapter |
| Form Factor |
Plug-in card - low profile |
| Interface (Bus) Type |
PCI Express 3.0 x8 |
| Networking |
|
| Ports |
10 Gigabit SFP+ x 2 |
| Connectivity Technology |
Wired |
| Data Link Protocol |
10 Gigabit Ethernet |
| Data Transfer Rate |
10 Gbps |
| Capacity |
Jumbo frame size: 9728 |
| Remote Management Protocol |
SNMP, RMON |
| Features |
Flow control, TCP/IP offloading, Virtual Machine Device Queues (VMDq), teaming support, PXE support, Large Send Offload (LSO), Receive Side Scaling (RSS), Single Root I/O Virtualization (SR-IOV), adaptive load balancing (ALB), Extended Message-Signaled Interrupts (MSI-X), UDP/IP offloading, Virtual Ethernet Port Aggregator (VEPA), Virtual Extensible LAN (VXLAN), Network Virtualization using Generic Routing Encapsulation (NVGRE) |
| Compliant Standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1Qbg, IEEE 802.1Qbh, IEEE 1588-2008 |
| Expansion / Connectivity |
|
| Interfaces |
2 x 10Gb Ethernet - SFP+ |
| Miscellaneous |
|
| Included Accessories |
Low-profile bracket |
| Compliant Standards |
C-Tick, EN 61000-3-2, EN55022, EN 61000-3-3, EN55024, RoHS, UL 94 V-1, AS/NZS CISPR 22, ICES-003 issue 4, FCC CFR47 Part 15 A |
| Dimensions & Weight |
|
| Width |
1.5 cm |
| Depth |
16.8 cm |
| Height |
6.9 cm |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 1 year |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
55 °C |
| Humidity Range Operating |
10 - 90% |
| Compatibility Information |
|
| Designed For |
Lenovo ThinkAgile HX2320 Appliance 7X83 ¦ Lenovo ThinkAgile HX3321 Certified Node 7Y89 ¦ Lenovo ThinkAgile HX3520-G Appliance 7X84 ¦ Lenovo ThinkAgile HX3721 Certified Node 7Y88 ¦ Lenovo ThinkAgile HX7520 Appliance 7X84 ¦ Lenovo ThinkAgile HX7820 Appliance 7Y95 ¦ Lenovo ThinkAgile HX7821 Certified Node 7Y96 ¦ Lenovo ThinkAgile VX 1U Certified Node 7Y93 ¦ Lenovo ThinkAgile VX Certified Node 7Y94, 7Z12 ¦ Lenovo ThinkAgile VX3320 Appliance 7Y93 ¦ Lenovo ThinkAgile VX3520-G Appliance 7Y94 ¦ Lenovo ThinkAgile VX3720 Appliance 7Y92 ¦ Lenovo ThinkAgile VX5520 Appliance 7Y94 ¦ Lenovo ThinkAgile VX7520 Appliance 7Y94 ¦ Lenovo ThinkAgile VX7820 Appliance 7Z13 ¦ Lenovo ThinkSystem SD530 ¦ Lenovo ThinkSystem SR250 ¦ Lenovo ThinkSystem SR530 ¦ Lenovo ThinkSystem SR550 ¦ Lenovo ThinkSystem SR570 ¦ Lenovo ThinkSystem SR590 ¦ Lenovo ThinkSystem SR630 ¦ Lenovo ThinkSystem SR650 ¦ Lenovo ThinkSystem SR670 7Y37 ¦ Lenovo ThinkSystem SR850 ¦ Lenovo ThinkSystem SR860 ¦ Lenovo ThinkSystem SR950 ¦ Lenovo ThinkSystem ST250 ¦ Lenovo ThinkSystem ST550 |
