Extended Spec
| General |
|
| Type |
Server |
| Product Form Factor |
Tower - 4U |
| Built-in Devices |
Led panel |
| Embedded Security |
Trusted Platform Module (TPM 1.2 and TPM 2.0) |
| Server Scalability |
1-way |
| Front Accessible Bays Qty |
2 |
| Hot-Swap Bays Qty |
4 |
| Localisation |
Region: EMEA |
| Processor / Chipset |
|
| CPU |
Intel Xeon E-2224 |
| Clock Speed |
3.4 GHz |
| Max Turbo Speed |
4.6 GHz |
| Number of Cores |
Quad-Core |
| CPU Qty |
1 |
| Max CPU Qty |
1 |
| Chipset Type |
Intel C246 |
| Cache Memory |
|
| Installed Size |
8 MB |
| Cache Per Processor |
8 MB |
| RAM |
|
| Installed Size |
16 GB / 128 GB (max) |
| Technology |
DDR4 SDRAM - ECC |
| Effective Memory Speed |
2666 MHz |
| Rated Memory Speed |
2666 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
4 (Total) / 3 (empty) |
| Features |
Unbuffered |
| Configuration Features |
1 x 16 GB |
| RAM Supported |
128 GB - Intel Xeon E processors - unbuffered ¦ 64 GB unbuffered |
| Hard Drive |
|
| Type |
No HDD |
| Storage Controller |
|
| Type |
1 x RAID |
| Controller Interface Type |
SATA 6Gb/s |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 10, JBOD |
| Optical Storage |
|
| Type |
No optical drive |
| Monitor |
|
| Monitor Type |
None. |
| Graphics Controller |
|
| Graphics Processor |
Matrox G200 |
| Video Interfaces |
VGA |
| Networking |
|
| Ethernet Ports |
2 x Gigabit Ethernet |
| Ethernet Controller |
Broadcom BCM5720 |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Controller |
XClarity Controller (XCC) Standard |
| Features |
PXE support, Teaming support |
| Expansion / Connectivity |
|
| Bays |
2 (total) / 2 (free) x external 5.25" x 1/2H ¦ 4 (total) / 4 (free) x hot-swap 3.5" |
| Slots |
1 (total) / 1 (free) x PCIe 3.0 x1 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height (x4 mode) ¦ 1 (total) / 1 (free) x M.2 Card |
| Interfaces |
3 x USB 3.1 Gen 1 (1 front, 2 rear) ¦ 1 x USB 2.0 (1 in front) ¦ 2 x USB 3.1 Gen 2 ¦ 1 x serial ¦ 1 x VGA ¦ 2 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x management - RJ-45 ¦ 1 x USB 3.0 (1 internal) |
| Miscellaneous |
|
| Theft/Intrusion Protection |
Security lock slot (cable lock sold separately), padlock loop |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
TUV GS, BSMI, EN 61000-3-2, EN 61000-3-3, EN55024, CB, CCC, IEC 60950-1, EN 60950-1, FCC CFR47 Part 15 B, GB 17625.1, GB 9254 Class A, CECP, GB 4943.1, BIS, NOM-019, EK1-ITB2000, CNS 13438 Class A, KN35, ICES-003 issue 6 Class A, AS/NZS CISPR 32 Class A, KN32 Class A, CNS 14336-1, EN 62368-1, IEC 62368-1, EN 55032 Class A, TR CU 020/2011, TR CU 004/2011, UL 62368-1, ASHRAE Class A2 |
| Power |
|
| Device Type |
Power supply - hot-plug |
| Power Redundancy |
Optional |
| Power Redundancy Scheme |
1+1 (with optional power supply) |
| Installed Qty |
1 |
| Max Supported Qty |
2 |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Provided |
550 Watt |
| 80 PLUS Certification |
80 PLUS Platinum |
| Operating System / Software |
|
| OS Provided |
No operating system |
| Environmental Standards |
|
| ENERGY STAR Certified |
Yes |
| ENERGY STAR Version |
2.1 |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 1 year - on-site - response time: next business day |
| Dimensions & Weight |
|
| Width |
17.5 cm |
| Depth |
56.57 cm |
| Height |
43 cm |
| Weight |
23.56 kg |
