Extended Spec
| General |
|
| Device Type |
Network adapter |
| Form Factor |
Plug-in card - low profile |
| Interface (Bus) Type |
PCI Express 2.1 x4 |
| PCI Specification Revision |
PCIe 2.1 |
| UNSPSC Information |
43201404 - Network interface cards |
| Networking |
|
| Ports |
Gigabit Ethernet x 2 |
| Connectivity Technology |
Wired |
| Cabling Type |
Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data Transfer Rate |
1 Gbps |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3az |
| Expansion / Connectivity |
|
| Interfaces |
2 x 1000Base-T - RJ-45 |
| Miscellaneous |
|
| Included Accessories |
Low-profile bracket |
| Compliant Standards |
FCC Class B certified, DOC-B, EN 60950, UL 1950, VCCI-II, EN55024, UL 60950, WHQL, EN55022 Class B, EN55024 Class B, RoHS, ACPI 1.1a |
| Power |
|
| Power Consumption Operational |
4.2 Watt |
| Software / System Requirements |
|
| OS Required |
Red Hat Enterprise Linux WS 4, SUSE Linux Enterprise Desktop 11, SUSE Linux Enterprise Desktop 10, Red Hat Enterprise Linux WS 5, Microsoft Windows 7 Professional (32/64 bits), Red Hat Enterprise Linux WS 6 |
| Dimensions & Weight |
|
| Depth |
13.5 cm |
| Height |
6.4 cm |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
55 °C |
| Humidity Range Operating |
10 - 95% (non-condensing) |
| Compatibility Information |
|
| Designed For |
HP Workstation Z1 G5 Entry, Z2 G4, Z4 G4, Z440, Z6 G4, Z8 G4 |
