Extended Spec
| General |
|
| Type |
Server |
| Product Form Factor |
Tower - 4U |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability |
1-way |
| Hot-Swap Bays Qty |
8 |
| Processor / Chipset |
|
| CPU |
No CPU |
| Max CPU Qty |
1 |
| CPU Upgradability |
Upgradable |
| Chipset Type |
Intel C256 |
| RAM |
|
| Installed Size |
0 GB (installed) / 128 GB (max) |
| Technology |
DDR4 SDRAM - ECC |
| Form Factor |
DIMM 288-pin |
| Slots |
4 (Total) / 4 (empty) |
| Features |
Unbuffered |
| Hard Drive |
|
| Type |
No HDD |
| Storage Controller |
|
| Type |
1 x RAID |
| Controller Interface Type |
SATA 6Gb/s |
| Channel Qty |
6 |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 10 |
| Optical Storage |
|
| Type |
No optical drive |
| Monitor |
|
| Monitor Type |
None. |
| Graphics Controller |
|
| Video Interfaces |
VGA |
| Networking |
|
| Ethernet Ports |
2 x Gigabit Ethernet |
| Ethernet Controller |
Broadcom BCM5720 |
| Data Link Protocol |
Ethernet, Gigabit Ethernet, Fast Ethernet |
| Remote Management Protocol |
IPMI 2.0, SMASH CLP, SNMP 3 |
| Remote Management Controller |
Integrated Lights-Out 5 |
| Features |
PXE support |
| Expansion / Connectivity |
|
| Bays |
8 (total) / 8 (free) x hot-swap 2.5" SFF |
| Slots |
1 (total) / 1 (free) x PCIe 4.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x4 mode) ¦ 2 (total) / 2 (free) x PCIe 3.0 x8 - half-length, full-height (x4 mode) ¦ 1 (total) / 1 (free) x M.2 Card (PCIe x2 and SATA mode) |
| Interfaces |
1 x VGA ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x LAN (Gigabit Ethernet) / HPE iLO ¦ 6 x USB 3.0 (1 front, 4 rear, 1 internal) ¦ 1 x USB 2.0 (1 in front) |
| Miscellaneous |
|
| Included Accessories |
Non-hot plug non-redundant system fan |
| Theft/Intrusion Protection |
Security lock slot (cable lock sold separately), padlock loop |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
EMC, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.3, UEFI, TLS v1.2 |
| Pricing Type |
CTO |
| Operating System / Software |
|
| Software |
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
| Dimensions & Weight |
|
| Width |
17.5 cm |
| Depth |
47.5 cm |
| Height |
36.83 cm |
| Weight |
10.1 kg |
| Environmental Parameters |
|
| Min Operating Temperature |
10 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
8 - 90% RH (non-condensing) |
| Sound Emission |
27 dBA |
