Extended Spec
General |
|
Type |
Server |
Bundled Services |
3 Years Basic Support with Next Business Day Onsite Service |
Product Form Factor |
Tower |
Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
Server Scalability |
1-way |
Hot-Swap Bays Qty |
8 |
Colour |
Black |
Processor / Chipset |
|
CPU |
Intel Xeon E-2314 |
Clock Speed |
2.8 GHz |
Max Turbo Speed |
4.5 GHz |
Number of Cores |
Quad-Core |
CPU Qty |
1 |
Max CPU Qty |
1 |
Processor Main Features |
Turbo 65W |
Cache Memory |
|
Installed Size |
8 MB |
Cache Per Processor |
8 MB |
RAM |
|
Installed Size |
16 GB / 128 GB (max) |
Technology |
DDR4 SDRAM - ECC |
Effective Memory Speed |
3200 MHz |
Rated Memory Speed |
3200 MHz |
Form Factor |
DIMM 288-pin |
Slots |
4 (Total) / 3 (empty) |
Features |
Unbuffered |
Configuration Features |
1 x 16 GB |
Hard Drive |
|
Type |
SSD - hot-swap - 2.5" |
Capacity |
1 x 480 GB |
Interface Type |
SATA 6Gb/s |
Features |
1 DWPD, Read Intensive, advanced format 512 |
Storage Controller |
|
Type |
1 |
Storage Controller Name |
PERC H355 |
Optical Storage |
|
Type |
No optical drive |
Monitor |
|
Monitor Type |
None. |
Graphics Controller |
|
Graphics Processor |
Matrox G200 |
Video Memory |
16 MB |
Video Interfaces |
VGA |
Networking |
|
Interface (Bus) Type |
LAN-on-motherboard (LOM) |
Ethernet Ports |
2 x Gigabit Ethernet |
Ethernet Controller |
Broadcom BCM5720 |
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
Remote Management Controller |
Integrated Dell Remote Access Controller 9 Enterprise 15G (iDRAC9 15G) |
Expansion / Connectivity |
|
Bays |
8 (total) / 7 (free) x hot-swap 3.5" |
Interfaces |
2 x LAN (Gigabit Ethernet) ¦ 5 x USB 2.0 ¦ 2 x USB 3.0 (1 front, 1 rear) ¦ 1 x VGA - DB-15 ¦ 1 x management - micro-USB (1 in front) (iDRAC Direct port) ¦ 1 x serial - DB-9 |
Miscellaneous |
|
Included Accessories |
Bezel, power cord (EU) |
Compliant Standards |
CCC |
Pricing Type |
Build To Plan (BTP) |
Manufacturer Selling Program |
Dell Smart Selection, Dell Smart Value |
Power |
|
Device Type |
Power supply - hot-plug |
Power Redundancy |
Optional |
Power Redundancy Scheme |
1+1 (with optional power supply) |
Installed Qty |
1 |
Max Supported Qty |
2 |
Voltage Required |
AC 220 V |
Power Provided |
700 Watt |
80 PLUS Certification |
80 PLUS Titanium |
Operating System / Software |
|
OS Provided |
No operating system |
Dimensions & Weight |
|
Width |
17.5 cm |
Height |
38.25 cm |
Weight |
25.34 kg |
