Extended Spec
| General |
|
| Type |
Server |
| Bundled Services |
3 Years Basic Support with Next Business Day Onsite Service |
| Product Form Factor |
Tower |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability |
1-way |
| Hot-Swap Bays Qty |
8 |
| Colour |
Black |
| Processor / Chipset |
|
| CPU |
Intel Xeon E-2314 |
| Clock Speed |
2.8 GHz |
| Max Turbo Speed |
4.5 GHz |
| Number of Cores |
Quad-Core |
| CPU Qty |
1 |
| Max CPU Qty |
1 |
| Processor Main Features |
Turbo 65W |
| Cache Memory |
|
| Installed Size |
8 MB |
| Cache Per Processor |
8 MB |
| RAM |
|
| Installed Size |
16 GB / 128 GB (max) |
| Technology |
DDR4 SDRAM - ECC |
| Effective Memory Speed |
3200 MHz |
| Rated Memory Speed |
3200 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
4 (Total) / 3 (empty) |
| Features |
Unbuffered |
| Configuration Features |
1 x 16 GB |
| Hard Drive |
|
| Type |
SSD - hot-swap - 2.5" |
| Capacity |
1 x 480 GB |
| Interface Type |
SATA 6Gb/s |
| Features |
1 DWPD, Read Intensive, advanced format 512 |
| Storage Controller |
|
| Type |
1 |
| Storage Controller Name |
PERC H355 |
| Optical Storage |
|
| Type |
No optical drive |
| Monitor |
|
| Monitor Type |
None. |
| Graphics Controller |
|
| Graphics Processor |
Matrox G200 |
| Video Memory |
16 MB |
| Video Interfaces |
VGA |
| Networking |
|
| Interface (Bus) Type |
LAN-on-motherboard (LOM) |
| Ethernet Ports |
2 x Gigabit Ethernet |
| Ethernet Controller |
Broadcom BCM5720 |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Controller |
Integrated Dell Remote Access Controller 9 Enterprise 15G (iDRAC9 15G) |
| Expansion / Connectivity |
|
| Bays |
8 (total) / 7 (free) x hot-swap 3.5" |
| Interfaces |
2 x LAN (Gigabit Ethernet) ¦ 5 x USB 2.0 ¦ 2 x USB 3.0 (1 front, 1 rear) ¦ 1 x VGA - DB-15 ¦ 1 x management - micro-USB (1 in front) (iDRAC Direct port) ¦ 1 x serial - DB-9 |
| Miscellaneous |
|
| Included Accessories |
Bezel, power cord (EU) |
| Compliant Standards |
CCC |
| Pricing Type |
Build To Plan (BTP) |
| Manufacturer Selling Program |
Dell Smart Selection, Dell Smart Value |
| Power |
|
| Device Type |
Power supply - hot-plug |
| Power Redundancy |
Optional |
| Power Redundancy Scheme |
1+1 (with optional power supply) |
| Installed Qty |
1 |
| Max Supported Qty |
2 |
| Voltage Required |
AC 220 V |
| Power Provided |
700 Watt |
| 80 PLUS Certification |
80 PLUS Titanium |
| Operating System / Software |
|
| OS Provided |
No operating system |
| Dimensions & Weight |
|
| Width |
17.5 cm |
| Height |
38.25 cm |
| Weight |
25.34 kg |
