ATEN VanCryst VM0404HB 4 x 4 True 4K HDMI Matrix Switch - Video/audio switch - desktop, rack-mountable

ATEN | VM0404HB
VM0404HB
VM0404HB
VM0404HB
VM0404HB
VM0404HB
VM0404HB
VM0404HB
VM0404HB
VM0404HB
VM0404HB
  • Connects any of 4 HDMI sources to any of 4 HDMI displays
  • Supports True 4K resolutions up to 4096 x 2160 @ 60Hz (4:4:4)
  • Multiple control methods - system management via front-panel pushbuttons, IR remote, RS-232 control, and Web GUI/Telnet via Ethernet connections
  • HDMI (3D, Deep Color, 4K) and HDCP 2.2 compatible
Getting product prices...

Extended Spec

General
Device Type Video/audio switch
Enclosure Type Desktop, rack-mountable 1U
Subtype HDMI
Performance Data transfer rate: 18 Gbps
Max Resolution 4096 x 2160 / 3840 x 2160 @ 60 Hz
Max Video Bandwidth 600 MHz
Features Firmware upgradable, 3D support, 4K resolution support, metal housing, Dolby TrueHD support, DTS-HD Master Audio support, EDID Expert
Compliant Standards HDCP 2.2
Built-in Devices Status LCD
Expansion / Connectivity
Interfaces 4 x HDMI input ¦ 4 x HDMI output ¦ 1 x serial (RS-232) DB-9 management ¦ 1 x management (LAN) RJ-45 ¦ 1 x remote control (IrDA) mini-jack
Power
Power Device External power adapter
Voltage Required AC 120/230 V
Power Consumption Operational 17.8 Watt
Miscellaneous
Included Accessories Remote control, IR receiver
Rack Mounting Kit Included
Compliant Standards FCC Part 15, RoHS, CEC
Dimensions & Weight
Width 43.72 cm
Depth 15.28 cm
Height 4.4 cm
Weight 2.47 kg
Manufacturer Warranty
Service & Support Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
Humidity Range Operating 0 - 80% (non-condensing)
Min Storage Temperature -20 °C
Max Storage Temperature 60 °C
