| General |
|
| Device Type |
Switch - 48 ports - L3 - Managed - stackable |
| Enclosure Type |
Rack-mountable 1U |
| Subtype |
5 Gigabit Ethernet |
| Ports |
48 x 100/1000/2.5G/5GBase-T (UPOE) |
| Power Over Ethernet (PoE) |
UPOE |
| PoE Budget |
645 W |
| Performance |
Switching capacity: 640 Gbps ¦ Stacking bandwidth: 480 Gbps ¦ Forwarding rate: 476.19 Mpps |
| Capacity |
QoS queues: 8 ¦ Member ports per aggregated link: up to 8 ¦ VLANs with trunking: 4094 |
| MAC Address Table Size |
32000 entries |
| Max Units In A Stack |
8 |
| Routing Protocol |
MSTP, RSTP, STP, IGMP, static IP routing, OSPFv2, VRRP |
| Remote Management Protocol |
SNMP, Syslog, DHCP, IPv4, IPv6 |
| Authentication Method |
RADIUS |
| Features |
Cisco StackPower technology, adaptive policy, ZTP, usage statistics, firmware upgradable, network diagnostics, push notification, QoS, DSCP to CoS Mutation, VLAN support, VLAN trunking, PVST, RPVST, STP BPDU Guard, STP loop guard, STP Root Guard, UDLD, Broadcast Storm Control, CDP, port mirroring, PIM, DHCP server, DHCP relay, RBAC, MAB, sticky MAC, DHCP snooping, DAI, ACL support, hot swappable 3 fans |
| Compliant Standards |
IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.3bt |
| Built-in Devices |
3 x fans |
| Status Indicators |
Status |
| Expansion / Connectivity |
|
| Interfaces |
48 x 100/1000/2.5G/5GBase-T RJ-45 UPOE - 60 W ¦ 2 x network stack device ¦ 1 x management ¦ 1 x USB Type A ¦ 1 x USB Type B console |
| Expansion Slots |
1 (total) / 1 (free) x Expansion Slot |
| Power |
|
| Power Device |
Internal power supply - hot-plug |
| Installed Qty |
1 |
| Max Supported Qty |
2 |
| Power Redundancy |
Optional |
| Power Provided |
1100 Watt |
| Voltage Required |
AC 100-240 V (50 - 60 Hz) |
| 80 PLUS Certification |
80 PLUS Platinum |
| Miscellaneous |
|
| Rack Mounting Kit |
Included |
| MTBF |
198,647 hours |
| Compliant Standards |
AN/NZS 60950.1, CAN/CSA-C22.2 No. 60950-1, CISPR 22 Class A, CISPR 24, CISPR 32 Class A, CNS 13438, EN 300 386 V1.6.1, EN 55022 Class A, EN 55032, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN55024, FCC CFR 47 Part 15 Class A, ICES-003 Class A, IEC 60950-1, KN32, KN35, RoHS, TCVN 7189 Class A, TCVN 7317, UL 60950-1, V-2/2015.04, V-3/2015.04, VCCI-CISPR 32 Class A |
| Dimensions & Weight |
|
| Width |
44.5 cm |
| Depth |
56.4 cm |
| Height |
4.4 cm |
| Weight |
9.09 kg |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - advanced replacement - lifetime - response time: next business day |
| Environmental Parameters |
|
| Min Operating Temperature |
-5 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
5 - 90% |
| Min Storage Temperature |
-20 °C |
| Max Storage Temperature |
70 °C |
