Extended Spec
General |
|
Type |
Server |
Product Form Factor |
Tower |
Server Scalability |
1-way |
Internal Bays Qty |
4 |
Front Accessible Bays Qty |
2 |
UNSPSC Information |
43211501 - Computer servers |
Processor / Chipset |
|
Max CPU Qty |
1 |
CPU Upgradability |
Upgradable |
CPU Socket |
LGA1150 Socket |
Chipset Type |
Intel C222 |
RAM |
|
Installed Size |
0 GB / 32 GB (max) |
Technology |
DDR3 SDRAM - ECC |
Form Factor |
DIMM 240-pin |
Slots |
4 (Total) / 4 (empty) |
Features |
Unbuffered, dual channel memory architecture |
Hard Drive |
|
Type |
No HDD |
Storage Controller |
|
Type |
1 x SATA - integrated |
Controller Interface Type |
SATA 6Gb/s |
Channel Qty |
2 |
RAID Level |
RAID 0, RAID 1, RAID 5, RAID 10 |
Storage Controller (2nd) |
|
Type |
1 x SATA - integrated |
Controller Interface Type |
SATA 3Gb/s |
Channel Qty |
4 |
RAID Level |
RAID 0, RAID 1, RAID 5, RAID 10 |
Optical Storage |
|
Type |
DVD-Writer DVD-Writer |
Monitor |
|
Monitor Type |
None. |
Graphics Controller |
|
Type |
Integrated |
Graphics Processor |
ASPEED AST1300 |
Video Memory |
64 MB |
Video Interfaces |
VGA |
Networking |
|
Type |
Integrated |
Ethernet Ports |
2 x Gigabit Ethernet |
Ethernet Controller |
2 x Intel I210-AT |
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
Expansion / Connectivity |
|
Bays |
3 (total) / 3 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5" ¦ 2 (total) / 1 (free) x external 5.25" |
Slots |
1 (total) / 1 (free) x CPU ¦ 4 (total) / 4 (free) x DIMM 240-pin ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 ¦ 1 (total) / 1 (free) x PCIe 2.0 x8 (x4 mode) ¦ 3 (total) / 3 (free) x PCI ¦ 1 (total) / 1 (free) x MIO |
Interfaces |
1 x serial ¦ 2 x LAN (Gigabit Ethernet) ¦ 4 x USB 2.0 (2 front, 2 rear) ¦ 1 x VGA ¦ 1 x PS/2 keyboard / mouse ¦ 2 x USB 3.0 |
Miscellaneous |
|
Cables Included |
Serial ATA cable (3 pcs.) |
Compliant Standards |
FCC Class B certified, C-Tick, BSMI |
Power |
|
Device Type |
Power supply |
Nominal Voltage |
AC 120/230 V (50 - 60 Hz) |
Power Provided |
300 Watt |
80 PLUS Certification |
80 PLUS Bronze |
Operating System / Software |
|
Software |
ASUS System Web-based Management (ASWM) Enterprise |
Dimensions & Weight |
|
Width |
19 cm |
Depth |
43.5 cm |
Height |
42.3 cm |
Weight |
14 kg |
