ASUS TS110-E8-PI4 - Server - tower 1-way - no CPU up to - RAM 0 GB - no HDD - DVD-Writer - AST1300 - Gigabit Ethernet - monitor: none

ASUS | 90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
90SV022A-M01CE0
  • Powerful CPUs
  • Ultra-quiet and energy saving
  • PCI Express 3.0-ready with workstation expandability
  • Complete remote server management
Getting product prices...

Extended Spec

General
Type Server
Product Form Factor Tower
Server Scalability 1-way
Internal Bays Qty 4
Front Accessible Bays Qty 2
UNSPSC Information 43211501 - Computer servers
Processor / Chipset
Max CPU Qty 1
CPU Upgradability Upgradable
CPU Socket LGA1150 Socket
Chipset Type Intel C222
RAM
Installed Size 0 GB / 32 GB (max)
Technology DDR3 SDRAM - ECC
Form Factor DIMM 240-pin
Slots 4 (Total) / 4 (empty)
Features Unbuffered, dual channel memory architecture
Hard Drive
Type No HDD
Storage Controller
Type 1 x SATA - integrated
Controller Interface Type SATA 6Gb/s
Channel Qty 2
RAID Level RAID 0, RAID 1, RAID 5, RAID 10
Storage Controller (2nd)
Type 1 x SATA - integrated
Controller Interface Type SATA 3Gb/s
Channel Qty 4
RAID Level RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Type DVD-Writer DVD-Writer
Monitor
Monitor Type None.
Graphics Controller
Type Integrated
Graphics Processor ASPEED AST1300
Video Memory 64 MB
Video Interfaces VGA
Networking
Type Integrated
Ethernet Ports 2 x Gigabit Ethernet
Ethernet Controller 2 x Intel I210-AT
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Expansion / Connectivity
Bays 3 (total) / 3 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5" ¦ 2 (total) / 1 (free) x external 5.25"
Slots 1 (total) / 1 (free) x CPU ¦ 4 (total) / 4 (free) x DIMM 240-pin ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 ¦ 1 (total) / 1 (free) x PCIe 2.0 x8 (x4 mode) ¦ 3 (total) / 3 (free) x PCI ¦ 1 (total) / 1 (free) x MIO
Interfaces 1 x serial ¦ 2 x LAN (Gigabit Ethernet) ¦ 4 x USB 2.0 (2 front, 2 rear) ¦ 1 x VGA ¦ 1 x PS/2 keyboard / mouse ¦ 2 x USB 3.0
Miscellaneous
Cables Included Serial ATA cable (3 pcs.)
Compliant Standards FCC Class B certified, C-Tick, BSMI
Power
Device Type Power supply
Nominal Voltage AC 120/230 V (50 - 60 Hz)
Power Provided 300 Watt
80 PLUS Certification 80 PLUS Bronze
Operating System / Software
Software ASUS System Web-based Management (ASWM) Enterprise
Dimensions & Weight
Width 19 cm
Depth 43.5 cm
Height 42.3 cm
Weight 14 kg
