| General |
|
| Device Type |
Network surveillance / panoramic camera |
| Audio Support |
Yes: built-in speaker |
| Audio Formats |
AAC, PCM, G.726, G.722.1, MP2L2, G.711a, G.711u |
| Form Factor |
Dome |
| Connectivity Technology |
Wired |
| Width |
48.5 cm |
| Depth |
48.5 cm |
| Height |
48.7 cm |
| Weight |
17 kg |
| Camera |
|
| Type |
Colour - Day&Night - pan / tilt / zoom - outdoor |
| Digital Video Format |
MJPEG, H.264, H.265, H.265+, H.264+ |
| Max Digital Video Resolution |
2560 x 1440 |
| Motion Detection |
Yes |
| Digital Zoom |
16 |
| Exposure Range |
1/25 sec - 1/30000 sec |
| Minimum Illumination |
0.0005 lux - colour, panoramic - F1.4 - AGC on ¦ 0.0001 lux - B&W, panoramic - F1.4 - AGC on ¦ 0.0005 lux - colour, tracking - F1.2 - AGC on ¦ 0.0001 lux - B&W, tracking - F1.2 - AGC on ¦ 0 lux - IR |
| Infrared LEDs |
Yes |
| Infrared Distance |
500 m |
| Video Capture |
2560 x 1440, 50 Hz @ 25 fps ¦ 2560 x 1440, 50 Hz @ 50 fps ¦ 1920 x 1080, 50 Hz @ 25 fps ¦ 1920 x 1080, 50 Hz @ 50 fps ¦ 1280 x 960, 50 Hz @ 25 fps ¦ 1280 x 960, 50 Hz @ 50 fps ¦ 1280 x 720, 50 Hz @ 25 fps ¦ 1280 x 720, 50 Hz @ 50 fps ¦ 704 x 576, 50 Hz @ 25 fps ¦ 640 x 480, 50 Hz @ 25 fps ¦ 352 x 288, 50 Hz @ 25 fps ¦ 2560 x 1440, 60 Hz @ 30 fps ¦ 2560 x 1440, 60 Hz @ 60 fps ¦ 1920 x 1080, 60 Hz @ 30 fps ¦ 1920 x 1080, 60 Hz @ 60 fps ¦ 1280 x 960, 60 Hz @ 30 fps ¦ 1280 x 960, 60 Hz @ 60 fps ¦ 1280 x 720, 60 Hz @ 30 fps ¦ 1280 x 720, 60 Hz @ 60 fps ¦ 704 x 480, 60 Hz @ 30 fps ¦ 640 x 480, 60 Hz @ 30 fps ¦ 352 x 240, 60 Hz @ 30 fps |
| Features |
Manual white balance, Backlight Compensation (BLC), sharpness control, saturation control, brightness control, contrast control, image mirror, Wide Dynamic Range (WDR), face detection, Face Recognition, infrared cut filter, Privacy Mask Function, Highlight Compensation (HLC), NAS-Ready, Electronic Image Stabilizer (EIS), tamper-detection, notification picture to E-mail, Smart IR, notification picture to FTP, manual gain control, password protection, Region of Interest (ROI), intrusion detection, auto gain control, auto white balance, 300 preset positions, Pelco Protocol, audio exception detection, ONVIF (Profile S) support, ONVIF (Profile G) support, Licence plate recognition (LPR), watermark, Internet Server Application Programming Interface (ISAPI), IP address filtering, 3D digital noise reduction (DNR), HTTPs encryption, built-in gyroscope, event tracking, 8 patrols, 4 pattern scans, regional focus, regional exposure, up to 20 channels simultaneous live view, multiple targets tracking, environment noise filtering, Power-off Memory, 3 video streams, ONVIF (Profile T) support, 3D Positioning, Preset Freezing, PTZ Position Display, Automatic Network Replenishment (ANR), Proportional Zoom, Scalable Video Coding (SVC), Face Capture, body detection, Auto Tracing White Balance, optical defog, DarkFighter technology, vehicle arming, People Tracking, person arming, feature abstraction |
| Image Sensor |
|
| Type |
4 MP PS CMOS 1/1.8" |
| Lens Construction |
|
| Type |
Motorized zoom |
| Optical Zoom |
40 x |
| Focal Length |
240 mm |
| Lens Iris |
F/1.4, f/1.2 |
| Focus Adjustment |
Automatic, manual, semi-auto |
| Panning |
|
| Range (degree) |
0 to 360 |
| Speed (degree/sec) |
Up to 280 |
| Tilting |
|
| Range (degree) |
-20 to +90 |
| Speed (degree/sec) |
Up to 150 |
| Interfaces |
|
| Network Interface |
Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols |
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ICMP, SNMP, RTSP, RTP, HTTPS, UPnP, IPv4, IPv6, Bonjour, RTCP, PPPoE, SMB, IGMP, CIFS, NFS, ISAPI, ISUP, SDK |
| Control Interface |
RS-485 |
| Alarm Inputs Qty |
7 |
| Alarm Outputs Qty |
2 |
| Expansion / Connectivity |
|
| Ports |
LAN - RJ-45 ¦ Audio line in ¦ Audio line out ¦ Serial RS-485 |
| Miscellaneous |
|
| Compliant Standards |
IEEE 802.1x |
| Power |
|
| Power Requirements |
DC 36 V |
| Power Device |
90 Watt |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 3 years |
| Environmental Parameters |
|
| Min Operating Temperature |
-40 °C |
| Max Operating Temperature |
70 °C |
