| General |
|
| Device Type |
Network surveillance camera |
| Audio Support |
Yes |
| Form Factor |
Dome |
| Connectivity Technology |
Wired |
| Depth |
10.1 cm |
| Height |
4.9 cm |
| Weight |
300 g |
| Camera |
|
| Type |
Colour - Day&Night - fixed |
| Digital Video Format |
MJPEG, H.264, H.265, MPEG-4 AVC |
| Max Digital Video Resolution |
2016 x 2016 |
| Motion Detection |
Yes |
| Exposure Range |
1 sec - 1/16000 sec |
| Minimum Illumination |
0.18 lux - colour - F2.0 - 50 IRE ¦ 0.04 lux - B&W - F2.0 - 50 IRE |
| Digital Video Capture Resolution |
2560 x 1920, 1920 x 1440, 256 x 192, 2560 x 1440, 160 x 160, 2016 x 2016, 256 x 144, 192 x 72, 2368 x 1184 |
| Frame Rate (max) |
60 frames per second |
| RAM |
512 MB |
| Flash Memory |
1 GB |
| Features |
Sharpness control, white balance, Wide Dynamic Range (WDR), AXIS Video Hosting System (AVHS), ONVIF support, infrared cut filter, Video Motion Detection Technology, active tampering alarm, digital PTZ function, 360° monitoring, Variable Bitrate (VBR), video analytics, Zipstream technology, ONVIF (Profile S) support, ONVIF (Profile G) support, Pixel Counter Support, digest authentication, ONVIF (Profile T) support |
| Image Sensor |
|
| Type |
6 MP RGB CMOS 1/1.8" |
| Total Pixels |
3072 x 2048 |
| Lens Construction |
|
| Type |
Fixed focal |
| Focal Length |
1.6 mm |
| Lens Iris |
F/2.0 fixed iris |
| Horizontal Field of View (degree) |
185 |
| Panning |
|
| Range (degree) |
-180 to +180 |
| Interfaces |
|
| Network Interface |
Ethernet 10Base-T/100Base-TX |
| Network Protocols |
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, SSL, QOS, CIFS, EAP, SFTP |
| Expansion / Connectivity |
|
| Ports |
LAN/power - RJ-45 |
| Supported Memory Cards |
microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous |
|
| Compliant Standards |
CISPR 22 Class A, EN55024, EN 61000-6-1, ICES-003 Class A, EN 61000-6-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, VCCI Class A, KN35, EN 62368-1, EN 55032 Class A, KCC KN32 Class A, IEEE 802.1x |
| Colour |
White |
| Power |
|
| Power Requirements |
PoE |
| Power Device |
6.49 Watt |
| Software / System Requirements |
|
| Software Included |
Windows decoder 1-user licence |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 3 years |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Relative Humidity (operating) |
10 - 85% (non-condensing) |
