| General |
|
| Printer Fonts |
PCL x 93 ¦ Bitmapped PCL x 10 ¦ PostScript x 136 |
| Device Type |
Multifunction printer |
| Printing Technology |
Laser - monochrome |
| Display Diagonal Size |
7" |
| Display Colour Support |
Colour |
| Display Features |
Touch screen, LCD display |
| Connection Availability |
Yes |
| Interface |
USB 2.0, Gigabit LAN, Wi-Fi(n), USB 2.0 host |
| AirPrint Enabled |
Yes |
| Office Machine Features |
Print from USB flash drive, scan to e-mail, scan to network, Data Security, scan to Cloud, scan to FTP, scan to SMB, Push Scan, fax to e-mail, Pull Scan, Color Network ScanGear2, fax to SMB, fax to FTP, Department ID, print from cloud, scan to USB host, scan to mobile device |
| Memory |
|
| Standard Memory |
2 GB |
| Copying |
|
| Max Copying Speed |
Up to 25 ppm |
| Max Copying Resolution |
Up to 600 x 600 dpi |
| Max Document Enlargement |
400% |
| Max Document Reduction |
25% |
| Preset Enlargements |
141%, 200%, 400%, 100% |
| Preset Reductions |
25%, 50%, 70% |
| Maximum Copies |
9999 |
| Copying Features |
ID Card Copy, Preset Reduction/Enlargement Ratios, Sort, Frame Erase Copy, Job Build, watermark, adjustable copy density, N-in-1, interrupt mode, book to two pages |
| Printing |
|
| Max Printing Resolution |
Up to 600 x 600 dpi |
| Max Printing Speed |
Up to 25 ppm |
| Printer Drivers / Emulations |
PCL 6, PDF, TIFF, XPS, UFRII, JPEG, EPS |
| Automatic Duplexing |
Yes |
| Scanning |
|
| Optical Resolution |
600 x 600 dpi |
| Document & Media Handling |
|
| Max Original Size |
297 x 432 mm |
| Original Type |
Sheets, books |
| Min Media Size |
95 x 139.7 mm |
| Max Media Size |
A3 |
| Min Media Weight |
60 g/m² |
| Max Media Weight |
157 g/m² |
| Supported Media Type |
Transparencies, envelopes, plain paper, labels, recycled paper, bond paper, heavy-weight paper, thin paper, punched paper, coloured paper |
| Supported Media Sizes |
A4 (210 x 297 mm), A5 (148 x 210 mm), B5 (176 x 250 mm), A3 (297 x 420 mm), B4 (250 x 353 mm), 297 x 431.8 mm, 95 x 139.7 mm |
| Supported Envelope Sizes |
International DL (110 x 220 mm), Com-10 (105 x 241 mm), International C5 (162 x 229 mm), Monarch (98.4 x 190.5 mm) |
| Standard Media Capacity |
330 sheets |
| Max Media Capacity |
580 sheets |
| Output Trays Capacity |
250 sheets |
| Document & Media Handling Details |
Paper cassette - A3 (297 x 420 mm) weight: 64 g/m² - 90 g/m² ¦ Bypass tray size: 95 x 139.7 mm - 297 x 431.8 mm weight: 60 g/m² - 157 g/m² ¦ Output tray - 250 sheets ¦ Platen |
| Speed Details |
Printing: up to 25 ppm (A4) ¦ Printing: up to 12 ppm (A3) ¦ Copying: up to 25 ppm (A4) ¦ Copying: up to 12 ppm (A3) |
| Connections |
|
| Interfaces |
1 x USB 2.0 - 4 pin USB Type B ¦ 1 x Gigabit LAN - RJ-45 ¦ 3 x USB 2.0 host - 4 pin USB Type A |
| Security Protocols & Features |
LDAP, Secure Print, TLS, IPsec, 802.1x, IP filtering, MAC address filtering, SNMP 3 |
| Operating System Support |
MS Windows 7, MS Windows Server 2008, MS Windows Server 2008 R2, MS Windows Server 2012, Android, iOS, Windows 8.1, MS Windows Server 2012 R2, Apple Mac OS X 10.10 or later, Windows 10, MS Windows Server 2016, MS Windows Server 2019 |
| Software Included |
Drivers & Utilities, iW Management Console, uniFLOW online Express, Canon Driver Configuration Tool |
| Power |
|
| Voltage Required |
AC 230 V (50/60Hz) |
| Power Consumption Operational |
1.5 kW |
| Power Consumption Standby |
22.1 Watt |
| Power Consumption Sleep |
1 Watt |
| Miscellaneous |
|
| Warm-Up Time |
12 sec |
| First Copy Out Time B/W |
7.4 sec |
| Environmental Standards |
|
| Blue Angel Compliant |
Yes |
| Dimensions & Weight |
|
| Width |
62.7 cm |
| Depth |
66.5 cm |
| Height |
51.6 cm |
| Weight |
34.2 kg |
| Environmental Parameters |
|
| Sound Emission |
54 dB (operating) |
| Min Operating Temperature |
10 °C |
| Max Operating Temperature |
30 °C |
| Humidity Range Operating |
20 - 80% |
