Extended Spec
| General |
|
| Device Type |
UPS - rack-mountable / external |
| Height (Rack Units) |
2U |
| Colour |
Black |
| UNSPSC Information |
39121011 - Uninterruptible power supply UPS |
| Power Device |
|
| UPS Technology |
On-line |
| Input Voltage |
AC 220/230/240 V |
| Input Voltage Range |
AC 160 - 275 V |
| Input Voltage Range (Adjustable) |
AC 100 - 275 V |
| Frequency Required |
40 - 70 Hz |
| Input Connectors |
1 x power IEC 60320 C20 |
| Power Output Connectors Details |
8 x power IEC 60320 C13 ¦ 2 x power IEC 60320 C19 |
| Output Voltage |
AC 220/230/240 V 50/60 Hz |
| Power Capacity |
2700 Watt / 3000 VA |
| Output Waveform |
Sinewave |
| Surge Suppression |
Yes |
| Surge Energy Rating |
340 Joules |
| Efficiency |
92% |
| Battery |
|
| Technology |
Lead Acid Lead Acid |
| Run Time (Up To) |
4 min at full load ¦ 11.8 min at half load |
| Recharge Time |
3 hours |
| Expansion / Connectivity |
|
| Interfaces |
1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x EPO (emergency power off) ¦ 1 x management (USB) - 4 pin USB Type A |
| Expansion Slots |
1 (total) / 1 (free) x SmartSlot |
| Networking |
|
| Remote Management Interface |
RS-232, USB |
| Miscellaneous |
|
| Included Accessories |
Vertical stand |
| Cables Included |
3 x power cable - external ¦ USB cable - external ¦ Network cable - external ¦ Power extension cable - external ¦ EPO cable |
| Rack Mounting Kit |
Included |
| Features |
Audible alarm, LCD display, internal bypass, Eco-Mode |
| Compliant Standards |
VDE, IEC 62040-2, RoHS, EN 62040-2, IP20, EAC, RCM, IEC 62040-1, EN 62040-1 |
| Software / System Requirements |
|
| Software Included |
APC PowerChute Business Edition |
| Environmental Standards |
|
| ENERGY STAR |
Yes |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 3 years ¦ Limited warranty - batteries - 2 years |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
0 - 95% (non-condensing) |
| Sound Emission |
55 dBA |
| Dimensions & Weight |
|
| Width |
43.2 cm |
| Depth |
63.5 cm |
| Height |
8.5 cm |
| Weight |
31.3 kg |
| Dimensions & Weight (Shipping) |
|
| Shipping Width |
59.9 cm |
| Shipping Depth |
87.1 cm |
| Shipping Height |
24.6 cm |
| Shipping Weight |
39.92 kg |
