| General |
|
| Device Type |
Switch - L3 - Managed |
| Enclosure Type |
Rack-mountable 2U |
| Subtype |
40 Gigabit Ethernet |
| Performance |
Latency (64-byte packets): 1 µs ¦ Throughput: up to 1429 Mpps ¦ Routing/switching capacity: 2560 Gbps |
| Capacity |
Virtual interfaces (VLANs): 4096 ¦ IPv4 routing table entries: 128000 ¦ IPv6 routing table entries: 64000 |
| MAC Address Table Size |
288K entries |
| Jumbo Frame Support |
10000 bytes |
| Routing Protocol |
OSPF, RIP, BGP-4, IS-IS, RIP-2, BGP, IGMP, VRRP, OSPFv3, VRRPE, static IPv6 routing, RIPng, BGP-4+, MPLS, Bidirectional Forwarding Detection (BFD) |
| Remote Management Protocol |
SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, SSH, SSH-2 |
| Authentication Method |
Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2) |
| Features |
Flow control, DHCP support, ARP support, port mirroring, Weighted Round Robin (WRR) queuing, SNTP support, Weighted Fair Queuing (WFQ), sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, Data Center Bridging Exchange (DCBX) support, Access Control List (ACL) support, Quality of Service (QoS), Committed Access Rate (CAR), Device Link Detection Protocol (DLDP) support, Equal-Cost Multipath (ECMP), LLDP support, Data Center Bridging (DCB), Registered State Change Notification (RSCN) support, Name Server-based zoning, Strict Priority (SP), Edge Virtual Bridging (EVB), redundant fans, reverse airflow support, Precision Time Protocol (PTP), FCoE support, RDMA over Converged Ethernet (RoCE), Virtual Ethernet Port Aggregator (VEPA), In-Service Software Upgrade (ISSU), FCoE Initialization Protocol (FIP), Shortest Path Bridging (SPB), Priority-Based Flow Control (PFC), Transparent Interconnection of Lots of Links (TRILL), Virtual Extensible LAN (VXLAN), Weighted Deficit Round Robin (WDRR) |
| Compliant Standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1aq, IEEE 802.3ag |
| RAM |
4 GB SDRAM |
| Flash Memory |
1 GB |
| UNSPSC Information |
43222612 - Network switches |
| Expansion / Connectivity |
|
| Interfaces |
1 x serial (console) RJ-45 ¦ 1 x management RJ-45 ¦ 1 x USB 2.0 |
| Expansion Slots |
4 (total) / 4 (free) x expansion slot |
| Installed Modules Qty (Max) |
0 (installed) / 4 (max) |
| Power |
|
| Power Device |
Internal power supply - hot-plug |
| Installed Qty |
0 (installed) / 4 (max) |
| Power Redundancy |
Optional |
| Miscellaneous |
|
| MTBF |
35.8 years |
| Compliant Standards |
FCC Class A certified, ETSI, CISPR 22 Class A, GOST, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, NOM, EN 61000-3-3, EN55022 Class A, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, RoHS, FCC CFR47 Part 15, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, ANATEL, EN 60825-1, ANSI C63.4-2003, EN 60825-2, EN 61000-3-2:2006, VCCI Class A, EN 61000-3-3:1995+A1:2001+A2:2005, EMC 2004/108/EC, EN 300 386 V1.3.3, FDA 21 CFR, CAN/CSA-C22.2 No. 60950-1, EN 55024:1998+A1:2001+A2:2003 |
| Dimensions & Weight |
|
| Width |
44 cm |
| Depth |
66 cm |
| Height |
8.81 cm |
| Weight |
27 kg |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 1 year |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
10 - 90% (non-condensing) |
