Extended Spec
| General |
|
| Device Type |
Radio access point |
| Ruggedized Design |
Indoor |
| Depth |
15 cm |
| Height |
4 cm |
| Weight |
380 g |
| Networking |
|
| Form Factor |
In-ceiling |
| Connectivity Technology |
Wireless |
| Line Coding Format |
CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM |
| Data Link Protocol |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Spread Spectrum Method |
OFDM, DSSS |
| Frequency Band |
2.4 GHz, 5 GHz |
| Performance |
Concurrent data rate (5 GHz): 867 Mbps ¦ Concurrent data rate (2.4 GHz): 400 Mbps ¦ Peak data rate: 1.3 Gbps |
| Capacity |
Wireless clients per Wi-Fi radio: 255 ¦ BSSIDs per radio: 16 |
| Status Indicators |
System, wireless |
| Features |
Auto-uplink (auto MDI/MDI-X), DFS support, Quality of Service (QoS), Trusted Platform Module (TPM), reset button, 2T2R MIMO technology, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Energy Efficient Ethernet, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cellular Coexistence (ACC), cyclic shift diversity (CSD), Aruba Beacons Bluetooth Low-Energy (BLE) technology, SU-MIMO technology, wireless intrusion protection, Air Monitor (AM) |
| Compliant Standards |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3az, IEEE 802.11ac |
| Aerial |
|
| Antenna |
Internal |
| Antenna Qty |
2 |
| Directivity |
Omni-directional |
| Expansion / Connectivity |
|
| Interfaces |
1 x 1000Base-T - RJ-45 |
| Miscellaneous |
|
| Included Accessories |
2 x ceiling mounting clip, ceiling mounting kit |
| MTBF |
753,457 hours |
| Compliant Standards |
EN 60950, IEC 60950, UL 60950, CB, UL 2043, FCC, EN 60601-1-2, cTUVus, FIPS, EN 300 328, EN 301 489, EN 60601-1-1, LVD 72/23/EEC, EN 301 893, R&TTE Directive 1995/5/EC |
| TAA Compliant |
Yes |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - lifetime |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
50 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
