Extended Spec
| General |
|
| Device Type |
Switch - 96 ports - Managed |
| Enclosure Type |
Rack-mountable 5U |
| Subtype |
Fast Ethernet |
| Ports |
96 x 10/100 |
| Routing Protocol |
IGMPv2, IGMP, IGMPv3 |
| Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c |
| Encryption Algorithm |
SSL |
| Authentication Method |
RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Features |
Routing, VLAN support, auto-uplink (auto MDI/MDI-X), manageable |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s |
| RAM |
64 MB SDRAM |
| Flash Memory |
24 MB Flash |
| UNSPSC Information |
43222612 - Network switches |
| Expansion / Connectivity |
|
| Interfaces |
1 x serial (RS-232) DB-9 management ¦ 96 x 100Base-TX RJ-45 |
| Expansion Slots |
8 (total) / 4 (free) x Expansion Slot |
| Installed Modules Qty (Max) |
4 (installed) / 8 (max) |
| Power |
|
| Power Device |
Internal power supply |
| Power Redundancy |
Yes |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Consumption Operational |
630 Watt |
| Miscellaneous |
|
| Rack Mounting Kit |
Included |
| Compliant Standards |
FCC Class A certified, CISPR 22 Class A, CISPR 24, EN 60950, EN 61000-3-2, EN55022, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, VCCI Class A ITE, EN 61000-3-3, EN55024, CSA 22.2 No. 950, UL 60950 |
| Dimensions & Weight |
|
| Width |
44.2 cm |
| Depth |
38.9 cm |
| Height |
22.2 cm |
| Weight |
14.7 kg |
| Environmental Parameters |
|
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
15 - 95% |
